Field assembly connectors for quick fiber termination in FTTH terminal boxes, wall outlets, ONT connections, and access network maintenance.
Fiber optic fast connectors are field assembly connectors designed for quick fiber termination in FTTH access networks, terminal boxes, wall outlets, indoor distribution, and access network maintenance. Unlike factory-terminated patch cords or pigtails, a fast connector is installed on-site by preparing the fiber end and securing it inside the connector body. Connector type, polish type, fiber or cable compatibility, and packaging should be confirmed according to the project requirement.
Request Quote Download DatasheetProduct Answer
What is fiber optic fast connector?
Fiber optic fast connectors are field-installable connectors designed for quick termination of fiber optic drop cables without epoxy or polishing. They are commonly used in FTTH installation, termination of drop cables at subscriber premises, and rapid network deployment.
Compare fast connector options to select the right type for your project.
| Requirement | Fast Connector | Field Splice Connector | Fusion Splice |
|---|---|---|---|
| Requirement | Fast Connector | Field Splice Connector | Fusion Splice |
| Installation | Mechanical (no epoxy) | Mechanical | Fusion splicer required |
| Fiber types | 250um / 900um / 3mm | 250um / 900um | Any fiber type |
| Typical IL | <0.5 dB typical | <0.5 dB | <0.1 dB |
| Best Pick | Quick FTTH termination | Field repair | Permanent low-loss |
Conservative specifications for Fiber Optic Fast Connectors. Final values depend on the project drawing.
| Layer | Component | Material / Function |
|---|---|---|
| 1 | Connector Housing | Plastic housing for field assembly and handling, subject to connector model |
| 2 | Ceramic Ferrule | Ferrule for connector-to-adapter alignment and optical interface |
| 3 | Fiber Alignment / Clamping | Mechanical alignment and clamping structure for prepared fiber end |
| 4 | Connector Interface | SC / LC / FC options, subject to project requirements |
| 5 | Polish Type | UPC / APC depending on connector type and network requirement |
| 6 | Boot & Dust Cap | Boot supports cable entry; dust cap protects ferrule end face before use |
| 7 | Cable Compatibility | 250 um / 900 um fiber, 2 mm / 3 mm cable, subject to connector model |
Typical values for reference. Final parameters depend on connector type, fiber preparation quality, cable compatibility, and installation procedure.
Typical values for reference. Final cable parameters depend on fiber type, construction, and customer specification.
| Parameter | Typical Guidance |
|---|---|
| Connector Types | SC, LC, and FC options, subject to project requirements |
| Polish Types | UPC / APC, subject to connector type and application |
| Fiber / Cable Compatibility | 250 um fiber, 900 um fiber, 2 mm cable, and 3 mm cable depending on connector model |
| Insertion Loss | Typical low-loss field termination; final value depends on fiber preparation, connector model, and test method |
| Documentation | Project-specific data and compliance documentation can be provided upon request when required |
On-site termination of prepared fiber ends in FTTH access networks.
Quick connector installation inside terminal boxes and distribution boxes.
Field termination at wall outlets and user-side fiber access points.
Subscriber-side fiber termination for access network equipment connection.
Fast field repair and restoration where fusion splicing is not preferred.
Indoor fiber distribution and access network quick termination work.
Configure your Fiber Optic Fast Connector requirements. Select connector type, fiber type, cable compatibility, assembly type, and application, then send your RFQ by WhatsApp or email.
Project-based quotation support with streamlined supply coordination from Dongguan, China.
Fiber optic product supply support for contractors, distributors, network installers, and international project buyers.
Flexible customization: connector type, fiber type, length, color, packaging, and labeling per your project requirements.
In-house insertion loss and return loss testing per TIA/EIA-568 standards. Batch test records and project documentation can be provided according to order requirements.
FCL and LCL shipping from Shenzhen port. Express courier for small-batch and sample orders.
Engineering support for product selection, specification review, and sample approval before mass production.
Fiber optic adapters for connector alignment and panel connection.
Pre-terminated patch cords for patching between panels and equipment.
SC pigtails for ODF, terminal box, and splice tray use.
Factory-terminated cable assemblies for fast deployment.
Fiber optic pigtails for fusion splicing and termination.
SC connector patch cables with single-mode and multimode options.
Send connector type, polish type, cable compatibility, packaging, and quantity for review.
