GYXTW53 Armored Outdoor Fiber Cable

GYXTW53 Armored Central Loose Tube Outdoor Fiber Optic Cable

Product Overview

GYXTW53 is an outdoor armored central loose tube fiber optic cable with PSP / corrugated steel tape armor and double PE sheath.

A typical structure includes optical fibers inside a single central loose tube, tube filling compound, water-blocking materials, strength members subject to final cable design, inner PE sheath, PSP / corrugated steel tape armor, and outer PE sheath. Fiber count, sheath material, armor structure, and mechanical performance should be confirmed according to final cable design and project requirements.

Request Quote Download Datasheet

Product Answer

What is GYXTW53 fiber optic cable?
GYXTW53 is an armored outdoor central loose tube fiber optic cable with PSP/steel tape armor and a double PE sheath. It is selected for duct, direct-buried, and outdoor access routes where compact central-tube construction and enhanced mechanical protection are required.

Quick Selection Guide

Key Takeaways

GYXTW53 combines PSP / steel tape armor with a double PE sheath for enhanced mechanical and environmental protection.
Central loose tube design supports 2–12 fibers for short to medium outdoor cable runs.
The double PE sheath provides enhanced moisture resistance for direct-buried and wet environments.
Suitable for direct-buried, duct, and harsh outdoor environments requiring high crush and rodent resistance.
For standard outdoor applications without double armor, GYXTW or GYXTS may be more cost-effective.

Citable Specification Notes

Operating temperature: Confirm the required range in the approved datasheet and project specification.
Bend radius: Confirm installation and operating limits against the final cable diameter and approved datasheet.
Armor and sheath: Confirm the final PSP armor and double-sheath construction in the approved cable design.
Water blocking: State the required design and acceptance criteria in the project specification.

Product Structure

GYXTW53 armored central loose tube fiber optic cable structure

GYXTW53 is an armored central loose tube outdoor fiber optic cable with enhanced moisture and mechanical protection. It is designed for duct, outdoor access, and underground routes where central loose tube design and stronger protection are required.

Central loose tubeOptical fibers are placed inside a central loose tube with filling compound or water-blocking protection according to project requirements.
Armored protectionSteel tape armor and reinforced sheath design improve crush resistance and route protection.
Double sheath designPE sheath layers provide outdoor environmental and moisture protection for demanding installation routes.

Layer	Component	Material / Function
1	Optical fiber unit	Fibers in central loose tube according to project fiber count.
2	Water blocking	Tube filling compound or water-blocking elements help protect the fiber unit.
3	Armor	Steel tape / PSP armor provides enhanced crush and mechanical protection.
4	Outer sheath	PE sheath protects the cable in duct, access, and underground routes.

General Optical Performance

Item	Typical Value / Option	Notes
Fiber type	G.652D / G.657A1 / G.657A2	Confirmed by project specification
Fiber count	2-288 fibers	Subject to final cable design
Sheath	PE / project-specified material	Confirmed by installation environment
Application	Duct / direct-buried / outdoor access route	Final use depends on route design
Standard	IEC 60794 series reference	Final test items confirmed before production

Key Features

Armored Central Loose Tube
Central loose tube design for outdoor cable routes.
Strength Member
Subject to final cable design (metallic or non-metallic per project).
PSP / Steel Tape Armor
Armor layer for enhanced mechanical protection.
Double PE Sheath
Inner PE sheath plus outer PE sheath for outdoor routes.
Water-Blocking Design
Tube filling and cable filling / water-blocking materials for moisture protection.
Duct and Direct-Buried Routes
Suitable for duct, direct-buried, feeder, and outdoor backbone networks.

Application Scenarios

Outdoor Duct Routes

Outdoor duct communication routes where armored protection and central loose tube structure are required.

Direct-Buried Projects

Routes requiring double sheath and armor protection, subject to project specification.

Backbone and Feeder Networks

Outdoor backbone and feeder routes in metro access and campus networks.

Industrial Communication Routes

Industrial and utility communication routes requiring enhanced mechanical protection.

GYXTW53 is not designed for ADSS routes, messenger-style aerial routes, or indoor drop cable applications.

Model Comparison: GYXTW53 vs Other Outdoor Fiber Cables

Compare GYXTW53 with related central loose tube and armored outdoor cable designs before confirming project requirements.

GYXTW53

Structure: Armored central loose tube outdoor cable with PSP / corrugated steel tape armor and double PE sheath.

Typical Use: Duct, direct-buried, outdoor access, and feeder routes requiring compact structure and reinforced protection.

Selection Note: Choose GYXTW53 when central loose tube design and 53-type armored protection are both required.

GYXTW

Structure: Central loose tube outdoor cable with compact construction and standard protection.

Typical Use: Access, distribution, and duct routes where 53-type double sheath is not required.

Selection Note: Use GYXTW when compact central tube design is needed without enhanced 53-type protection.

GYXTS

Structure: Central loose tube outdoor cable with steel tape protection.

Typical Use: Outdoor routes requiring steel tape protection but not necessarily double PE sheath design.

Selection Note: Confirm sheath, armor, and route requirements before choosing between GYXTS and GYXTW53.

GYFTY53

Structure: Non-metallic stranded loose tube cable with FRP central strength member and 53-type protection.

Typical Use: Outdoor routes requiring 53-type protection while avoiding a metallic central strength member.

Selection Note: Choose GYFTY53 when the project requires non-metallic central strength member design.

GYXTW53 Cable Configurator

Configure the key requirement for GYXTW53 Armored Central Loose Tube Outdoor Fiber Optic Cable. Select standard options or enter custom notes, then send your RFQ by WhatsApp or email.

Fiber Count / Core Count

Fiber Type / Connector Type

Jacket / Material

Installation / Application

Length / Drum Length

Quantity

Project Requirement

FAQ About GYXTW53 Armored Central Loose Tube Outdoor Fiber Optic Cable

Q: What is GYXTW53 fiber optic cable?

GYXTW53 is an outdoor armored central loose tube fiber optic cable with PSP / corrugated steel tape armor and double PE sheath. It is designed for duct, direct-buried, and outdoor access and backbone routes.

Q: Is GYXTW53 an all-dielectric cable?

No. GYXTW53 contains PSP / corrugated steel tape armor as a standard feature. Depending on the final cable design, strength members may be metallic or non-metallic.

Q: What is the difference between GYTA and GYXTW53?

GYTA is a stranded loose tube cable with APL moisture barrier and a single PE sheath for outdoor duct use. GYXTW53 adds corrugated steel tape / PSP armor and an outer PE sheath, making it suitable for direct burial and harsh outdoor environments.

Q: What is the difference between GYXTW53 and GYFTY53?

GYXTW53 uses a central loose tube design with PSP / steel tape armor. GYFTY53 uses a non-metallic stranded loose tube with FRP central strength member. Both have 53 armor structure (steel tape + double PE sheath).

Q: Can GYXTW53 be used for direct burial?

GYXTW53 is designed for duct, direct-buried, and outdoor access routes when the final cable design and project specification confirm the required armor, sheath, tensile, crush, and environmental parameters.

Q: What should be confirmed before production?

Please confirm fiber count, fiber type, strength member type, armor structure, sheath material, cable marking, drum length, installation route, mechanical requirements, and project standards.
